Dongguan LJV Rotary Pulse Encoder RE1104EG3-V01-3410

Type: incremental rotary encoder
Pulse per revolution: 15
Power rating: 5VDC 10mA (1mA min.)
Contact resistance: 100 milliohms max. @ initial
Insulation resistance: 100 mega ohms min. @ 250VDC 1mA
Dielectric strength: 300VAC for 1 minute (leak current 1mA)
Operating temperature range: -30℃ to +80℃
Detent: 30, step angle: 12°±2°
Storage temperature range: -40℃ to+85℃
Rotational lifespan: 30,000±200 cycles
Shaft play in axial direction: 0.4mm maximum
Shaft wobble: 0.6mm maximum
Total rotational angle: 360° (endless)
Detent torque: 2-15mN.m. (20-150gf.cm)
Bushing nut tighten strength: 8.0kgf.cm min
Shaft place in rotational wobble: 5° maximum

Dongguan LJV Video Incremental High Resolution Rotary Shaft Encoder:RE1601AB1-H01-016

Type: incremental rotary encoder
Pulse per revolution: 24
Power rating: 5VDC 10mA (1mA min.)
Contact resistance: 100 milliohms max. @ initial
Insulation resistance: 100 mega ohms min. @ 250VDC 1mA
Dielectric strength: 300VAC for 1 minute (leak current 1mA)
Operating temperature range: -30℃ to +80℃
Detent: 24, step angle: 15°±2°
Storage temperature range: -40℃ to+85℃
Rotational lifespan: 30,000±200 cycles
Shaft play in axial direction: 0.4mm maximum
Shaft wobble: 0.6mm maximum
Total rotational angle: 360° (endless)
Detent torque: 2-15mN.m. (20-150gf.cm)
Bushing nut tighten strength: 8.0kgf.cm min
Shaft place in rotational wobble: 5° maximum

ljv rotary encoder

Dongguan LJV 1Miniature Absolute Rotary Encoder RE1000EA-V01-0110

Type: Absolute rotary encoder
Channel: 16
Power Rating: 5VDC 10mA (1mA min.)
Contact Resistance: 100 milliohms max. @ initial
Insulation Resistance: 100 mega ohms min. @ 250VDC 1mA
Dielectric Strength: 300VAC for 1 minute (leak current 1mA)
Operating temperature range: -30℃ to+80℃
Detent: 16, Step angle: 20°±3°
Storage temperature range: -40℃ to+85℃
Rotational life: 30,000±200 cycles
Shaft play in axial direction: 0.4mm Max
Shaft wobble: 0.6mm Max
Total rotational angle: 300°±5°
Detent torque: 20～50mN.m.(200～500gf.cm)
Bushing nut tighten strength: 8.0kgf.cm Min
Shaft place in rotational wobble: 5°Max

Dongguan LJV RoHS Video Incremental Contacting Rotary Shaft Encoder RE1201XE1-H01-0385

Type: Incremental rotary encoder
Pulse per revolution: 24
Power Rating: 5VDC 10mA (1mA min.)
Contact Resistance: 100 milliohms max. @ initial
Insulation Resistance: 100 mega ohms min. @ 250VDC 1mA
Dielectric Strength: 300VAC for 1 minute (leak current 1mA)
Operating temperature range: -30℃ to +80℃
Detent: 24, Step angle:15°±2°
Storage temperature range: -40℃ to+85℃
Rotational life: 30,000±200 cycles
Shaft play in axial direction: 0.4mm Max
Shaft wobble: 0.6mm Max
Total rotational angle: 360°(Endless)
Detent torque: 2～15mN.m.(20～150gf.cm)
Bushing nut tighten strength: 8.0kgf.cm Min
Shaft place in rotational wobble: 5°Max

Select Function By LJV Rotary Potentiometer

First of all, we need to know that potentiometer is totally different from encoder. Potentiometer, which is abbreviated as pot, is mainly made up of resistive element and wiper in order to adjust resistance. When the wiper is moving alongside the resistive element, its displacement and the resistance between terminals and voltage are very much correlated. Pot is often refered to as variable resistor.

While enoder consists of encoding disk and wiper with pulse quadrature output.

In electronic industry, rotary encoder would be a best choice to  select the functions of appliances through menu ( that is exactly what encoder does!)

And here engineers from LJV would like to introduce you how to select functions by rotary potentiometer. As aforementioned, pot is used to control voltage and resistance, so is it possible to select functions through adjusting resistance? Yes, it could be done by writing a program to calculate the resistance and then convert it to angle which will be recognized by rotary potentiometer.

Rotary potentiometer may not be the best choice to select functions, but under some special conditions, it might be a better option. Several kinds of LJV rotary potentiometer, such as RP39 and RP09, etc., have been designed for this purpose. With its accurate angle locating and stable resistive element, LJV rotary potentiometer could greatly ensure your products stability.

Dongguan LJV RoHS Flat Metal Shaft Miniature Absolute Position Rotary Encoder

Type:Absolute rotary encoder
Channel:16
Power Rating:5VDC 10mA (1mA min.)
Contact Resistance:100 milliohms max. @ initial
Insulation Resistance:100 megaohms min. @ 250VDC 1mA
Dielectric Strength:300VAC for 1 minute (leak current 1mA)
Operating temperature range:-30℃ to+80℃
Detent:16, Step angle:20°±3°
Storage temperature range:-40℃ to+85℃
Rotational life:30,000±200 cycles
Shaft play in axial direction: 0.4mm Max
Shaft wobble:0.6mm Max
Total ratational angle:300°±5°
Detent torque:15～40mN.m.(150～400gf.cm)
Bushing nut tighten strength:8.0kgf.cm Min
Shaft place in rotational wobble:5°Max

LJV Absolute Rotary Encoder

LJV Absolute Rotary Encoder

Dongguan LJV Metal Shaft Industrial B10K Miniature Rotary Angular Audio Potentiometers

Type:Rotary Potentiometer
Resistance:B Typer 50K
Power Rating0.05w
Rated voltageDC 12V
Maximum operating current:1A Max
Insulation Resistance:100 megaohms min. @ 250VDC 1mA
Contact Resistance: 100 milliohms max. @ initial
Switch Rotation Torque: 80∽300 gf.cm
Bouncing: 10mS or less
Rotation life: 30,000±200 cycles
Total Rotational Angle:300°±5°
Stop Strength:3Kgf.cm Min
Detent torque:15～35mN.m.(150～350gf.cm)
Shaft play in axial direction:0.4mm Max
Detents and position:16 detents, Step angle:20°±2°
Bushing nut tighten strength:7.0Kgf.cm Min

Dongguan LJV Hollow Shaft Industrial B10K Linear Stereo Volume Rotary Large LED Potentiometers

Type: Rotary Potentiometer
Resistance:B Typer 10K
Power Rating:0.05w
Rated voltage:DC 12V
Maximum operating current:1A Max
Insulation Resistance:100 megaohms min. @ 250VDC 1mA
Contact Resistance:100 milliohms max. @ initial
Detent:8
Detent torque:280gf.cm -- 1000gf.cm
Rotation life:30,000±200 cycles
Total Rotational Angle:225°±5°
Stop Strength:3Kgf.cm Min
Shaft wobble:0.7*L/30mm p-p Max
Shaft play in axial direction:0.4mm Max
Bushing nut tighten strength:7.0Kgf.cm Min
Noise:less than 150mV p-p

LJV Hollow Shaft Rotary Potentiometer

LJV Hollow Shaft Rotary Potentiometer

LJV Hollow Shaft Rotary Potentiometer

Dongguan LJV Metal Dual Shaft A10K Linear Concentric Rotary Encoder Potentiometer

Type:Rotary Potentiometer
Resistance:B Typer 100K
Power Rating0.025w
Rated voltageDC 12V
Maximum operating current:1A Max
Insulation Resistance:100 megaohms min. @ 250VDC 1mA
Contact Resistance: 100 milliohms max. @ initial
Switch Rotation Torque: 80∽300 gf.cm
Bouncing: 10mS or less
Rotation life: 30,000±200 cycles
Total Rotational Angle:300°±5°
Stop Strength:3Kgf.cm Min
Detent torque:15～35mN.m.(150～350gf.cm)
Shaft play in axial direction:0.4mm Max
Detents and position:16 detents, Step angle:20°±2°
Bushing nut tighten strength:8.0Kgf.cm Min

REP08 LJV Dual Shaft Rotary Encoder Potentiometer

LJV Dual Shaft Rotary Encoder Potentiometer

Dongguan LJV Panel Mount Metal Shaft B500K Rotary Linear Taper Pot Meter Manufacturer

Type: Rotary Potentiometer
Resistance:B typer 200K
Power Rating:0.05w
Rated voltage:DC 12V
Maximum operating current:1A Max
Insulation Resistance:100 megaohms min. @ 250VDC 1mA
Contact Resistance:100 milliohms max. @ initial
Click Torque:50∽250 gf.cm
Switch rotation Torque:20-45gf.cm
Rotation life:10,000±200 cycles
Total Rotational Angle:300°±5°
Stop Strength:3Kgf.cm Min
Shaft wobble:0.7*L/30mm p-p Max
Shaft play in axial direction:0.4mm Max
Bushing nut tighten strength:7.0Kgf.cm Min
Noise:less than 150mV p-p

Dongguan LJV RoHS 200K Surface Mount Carbon Film Rotary Variable Resistor

Type: Rotary Potentiometer
Resistance:B typer 200K
Power Rating:0.05w
Rated voltage:DC 12V
Maximum operating current:1A Max
Insulation Resistance:100 megaohms min. @ 250VDC 1mA
Contact Resistance:100 milliohms max. @ initial
Click Torque:50∽250 gf.cm
Switch rotation Torque:20-45gf.cm
Rotation life:10,000±200 cycles
Total Rotational Angle:300°±5°
Stop Strength:3Kgf.cm Min
Shaft wobble:0.7*L/30mm p-p Max
Shaft play in axial direction:0.4mm Max
Bushing nut tighten strength:7.0Kgf.cm Min
Noise:less than 150mV p-p

Dongguan LJV RoHS Low Cost 1 Pole 4 Position Selector Rotary Switch Manufactures

Type: Home Appliance Rotary Switch
Character: 1 pole, 7 positions
Power Rating: DC 30V (0.3A Max.)
Contact Resistance: 100 milliohms max. @ initial
Insulation Resistance：100 megaohms min. @ 500VDC 1mA
Dielectric Strength：500VAC for 1 minute (leak current 1mA)
Rotation angle：51.4°±3°
Rotation Torque：600∽1000gf.cm
Bushing Nut Tighten Strength：8Kgf.cm
End stop strength：Apply 5Kgf.cm for 5 sec
Shaft play in axial direction：0.2mm Max
Shaft wobble: 0.7*L/30mm p-p Max
Ratation Life: 10,000±200cycles
Operating temperature range: -20℃ to+70℃
Storage temperature range: -40℃ to+85℃
Relative humidity:63％ to 67％

LJV General Introduction of Rotary Encoders, Rotary Potentiometers and Rotary Switches
